Taian Minle Machine Manufacture Co., Ltd. is mainly engaged in the production, research and development, and sales of concrete construction equipment, concrete shotcrete robot equipment, concrete mixer with pumps and so on.The company's main products are concrete pumps, pumping concrete mixers, concrete pump trucks, etc., which have been widely used in many construction engineering fields such as residential buildings, railways, water conservancy, construction tunnels, underground coal mines, and national defense.
Why Choose Us?
Professional Team
We boast 24 years of rich experience. Our workforce consists of 300 employees, among whom there are 15 senior engineers, 26 professional installation directors and technicians.
Quality Control
All products have obtained BV and ISO9001 international quality system certifications, and the coal mine concrete pump has acquired the mining product safety approval certificate.
Wide Market
Our concrete pumps have been exported to 65 countries and regions, such as North and South America, Africa, Europe, Oceania, and Southeast Asia, and the number is increasing year by year.
Excellent Service
We have the capacity to offer you the highest-quality concrete pumps and prompt delivery services. Our sales team is accessible 24 hours a day and 7 days a week.
-
Concrete Mixer with Concrete Pump
For the convenience of users, we install a mixer on top of the concrete pump. The power component
Add to Inquiry -
Diesel Driven Cement Mixer With Trailer Pump
diesel driven cement mixer with trailer pump,that is power source by diesel engine,driven hydraulic
Add to Inquiry -
small concrete mixer with a concrete pump is a powerful and versatile tool that combines the
Add to Inquiry -
Concrete pump concrete mixer used conveniently on building area, the Concrete Pump Concrete Mixer
Add to Inquiry -
The working of the concrete mixture pump needs water supply, the equipment equipped with the time
Add to Inquiry -
Concrete Mixing and Pumping Machine
Concrete pump function needed to be feeding concrete, it will be combined together at once using a
Add to Inquiry -
Portable Diesel Concrete Mixer with Pump
With the development of the construction industry, traditional concrete equipment is no longer
Add to Inquiry -
Diesel Concrete Blender with Pump
It is also called concrete mixer with concrete pump, Diesel Concrete blender with pump is a
Add to Inquiry -
Large Capacity Concrete Mixer Concrete Pump
Concrete mixer concrete pump with the water supplied by hydraulic power, the wet concrete pouring
Add to Inquiry
Our Hot Selling Diesel Concrete Mixer With Pump
Our Company Has More Products to Offer, Please Browse the Product Categories on the Website, If You Have Any Needs, Please Contact Us.
Concrete mixer with concrete pump
The power component of the concrete pump is a hydraulic system, and the power source is a diesel engine.The mixer and concrete pump combine into one body, which is easy to move and greatly improves work efficiency.
Diesel concrete mixer pump
Diesel concrete mixer pump is the new developed machine by our factory, we designed it according to the clients' request. It is concrete mixer mounted on the concrete pump, it was powered by diesel engine, two machines combined to one body - concrete mixer and concrete pump, it has double function, that are mixing and pumping.
Concrete mixer with conveyor
Small concrete mixer with a concrete pump is a powerful and versatile tool that combines the functionality of a concrete mixer and a concrete pump. The structure of this equipment includes a mixer drum, a mixing system, a hopper, a pump, and a boom attachment. The mixer drum allows for the mixing of the concrete while the pump transfers it to its desired location through the boom attachment.
Concrete pump concrete mixer
Concrete pump concrete mixer used conveniently on building area, the concrete pump concrete mixer with high efficient ways such as transport from one site to another, machine operation, maintain, the concrete pump concrete mixer can mix and delivery concrete to the destination area and you can getting it to where you need.
Concrete mixture pump
The working of the concrete mixture pump needs water supply, the equipment equipped with the time relay, it can meet the requirements of the automatic water supply, you can also set the supply time according your work condition, in this way, the machine can pruduce the good quality concrete for your building work.
Diesel Concrete Mixer with Pump Parameters
|
Power |
kw |
45 |
|
|
Whole machine |
Length |
mm |
4250 |
|
Width |
mm |
2100 |
|
|
Height |
mm |
2700 |
|
|
Weight |
kg |
4000 |
|
|
Mixer |
Mixer model |
/ |
JZM450 |
|
Theoretical mixing capacity |
m3/h |
15-25 |
|
|
Maximum aggregate size |
mm |
40 |
|
|
Working cycle time |
s |
72 |
|
|
Feeding height |
mm |
1400 |
|
|
Hopper capacity |
m3 |
0.65 |
|
|
Pumping system |
Theoretical pumping capacity |
m3/h |
40 |
|
Theoretical pumping pressure |
MPa |
8 |
|
|
Delivery cylinder |
/ |
200*800 |
|
|
Hydraulic system |
/ |
Open |
|
|
Distribution valve |
/ |
S valve |
|
|
System pressure |
MPa |
28 |
|
|
Delivery pipe diameter |
mm |
125 |
|
1. Masonry block filling
2. Concrete wall grouting
3. Refractory castable&shotcrete
4. Concrete shotcrete
5. Tunneling construction
6. Concrete wall construction
7. Mining support (sprayed concrete walls and ceilings)
8. Excavation-protection
9. Concrete sidewalk
10. Swimming pool (sprayed concrete shells)
Safety is paramount when operating a diesel concrete mixer with pump . Here are some safety measures to consider:
Personal Protective Equipment (PPE): Ensure that operators wear appropriate PPE, including helmets, gloves, eye protection, and steel-toed boots. These items protect against potential hazards on the job site.
Ventilation: Since diesel engines produce exhaust fumes, adequate ventilation is essential, especially when operating in enclosed spaces. If working indoors, ensure that the area is well-ventilated to prevent the buildup of harmful fumes.
Emergency Procedures: Establish emergency procedures for handling fuel spills, fires, or equipment malfunctions. Ensure that all operators are trained on these procedures.
Equipment Training: Provide comprehensive training for operators on the proper use of diesel concrete mixer pumps. Operators should understand the machine's functions, safety features, and emergency protocols.
Fire Safety: Keep fire extinguishers readily available and ensure that they are suitable for diesel fuel fires. Regularly inspect fire extinguishers to ensure they are in working order.
Cooperation Cases
Certificate
FAQ
We're well-known as one of the leading diesel concrete mixer with pump manufacturers and suppliers in China. Please rest assured to buy high quality diesel concrete mixer with pump for sale here from our factory. For price consultation, contact us.
