Self Propelled Shotcrete Pump
self walking wet concrete shotcrete truck which is a large-scale shotcrete with robotic arm, therefore we also called it is wet shotcrete manipulator, it is diesel driven for unit running, using hydraulic transmission, so the shotcrete truck can access to the construction tunnel quickly, after the work finished, it can be exit from the working face, convenient and flexible;
Description
Introduction
The Self-Propelled Shotcrete Pump is a concrete construction equipment that integrates spraying, pumping, and self-propelled travel. Its core advantages lie in its self-propelled chassis, high-pressure hydraulic pump system, and efficient mixing function. It is suitable for the construction needs of various scenarios such as mining, tunneling, water conservancy, and underground projects.
Advantages
Efficient Mixing and Conveying
With a mixing capacity of 350L–800L, the machine boasts a mixing time of just 3–6 minutes and can process a variety of materials, including sand, gravel, cement, and mortar.
Stable Powertrain
The standard 9HP diesel engine (electric motor drive optional) and a reinforced drive chain system ensure stability for long-term continuous operation.
Powerful Hydraulic Pumping Capacity
The built-in high-pressure hydraulic pump achieves a maximum pumping pressure of 35MPa, a conveying pipe length of up to 20m, and a vertical pumping height of 12m.
Flexible Self-Propelled Design
Equipped with a self-propelled chassis, operators can easily move the machine to the construction site, eliminating the need for additional towing equipment.
Product Customization
Power System: Available with either a diesel engine or electric motor, supporting various power levels.
Mixing Capacity: Customizable to 350L, 500L, or 800L.
Spray Arm Configuration: Available with standard nozzles or multi-angle spray arms.
Hydraulic Pump Parameters: Adjustable pumping pressure and delivery height.
Mobility: Available with a self-propelled chassis or trailer-mounted configuration.
Appearance and Branding: Customizable with your logo, color, and nameplate.
Accessories: Spare pipes, nozzles, and consumable parts kits are available.
Self Propelled Shotcrete Pump Parameter:
|
Parameter |
Item |
Unit |
ML-4015A Specification |
|
|
Total weight |
Kg |
15200 |
||
|
Dimensions(L×w×h) |
mm |
7900*2500*3200 |
||
|
power |
Kw/rpm |
85kw/2400rpm |
||
|
Emission Standards |
|
III |
||
|
Pumping system |
Drive method |
Hydrostatic transmission, four-wheel drive |
||
|
Steering method |
|
Four-wheel steering, two-way driving |
||
|
Brake system |
|
Oil brake |
||
|
Driving speed |
km/h |
≦17 |
||
|
power |
Kw |
45 |
||
|
Max.capacity |
m3/h |
30 |
||
|
Aggregate size |
mm |
Max. 16 |
||
|
Concrete slump |
cm |
120-200 |
||
|
Concrete delivery pressure |
MPa |
7.5 |
||
|
Concrete cylinder bore × stroke |
mm |
φ160x1000 |
||
|
Hopper capacity/Feeding height |
m3/m |
0.35/1.4 |
||
|
Robot parameters |
Maximum working range
|
up |
m |
15 |
|
forward |
m |
13 |
||
|
width |
m |
26 |
||
|
Big Boom swing angle |
° |
270° |
||
|
Big Boom pitch range |
° |
0- 70 ° |
||
|
Small boom Telescopic range |
m |
2x2.2 |
||
|
Nozzle seat axial rotation range |
° |
360 |
||
|
Nozzle seat axial swing range |
° |
240 |
||
|
Nozzle deflection angle x brushing |
|
8°x360° |
||
|
Operation method |
|
remote control |
||
|
Delivery pipe diameter |
mm |
90 |
||
|
type |
|
Screw |
||
|
Drive method |
Hydraulic motor + electric ratio |
|||
|
Max.capacity |
L/h |
700 |
||
|
Maximum delivery pressure |
Bar |
24 |
||
|
Electrical System |
Working voltage |
V |
380/50Hz |
|
|
control method |
Construction machinery dedicated controller + professional industrial control screen display |
|||
|
Cable specifications, length |
m |
(3*35+1)x80 |
||
Product details:
Application
The wet shotcrete machine has a wide range of applications and is customized for foreign engineering projects, such as foundation pit support, tunnel support, slope support, and roadway support.
Delivery:
Our factory has its own transport team for the delivery of the wet concrete shotcrete machine, ensuring prompt delivery.
Workshop:
Our professional production workshop guarantees quality assurance and on-time delivery.
Company Strength
Professional Team
The company employs over 300 people, including 15 senior engineers and 26 professional technicians. The engineering team specializes in product design and performance enhancement, while the installation team provides comprehensive installation guidance and user training.
Advanced Production Equipment
Equipped with key equipment such as CNC machining centers, plasma cutters, large drilling machines, and surface grinders. Multiple fixtures and inspection tools ensure component precision and overall assembly quality.
Strict Quality Management
From raw material procurement and component processing to complete machine testing, strict controls are implemented. We have obtained BV and ISO9001 international certifications, and our coal mine concrete pumps have received the National Mining Product Safety Mark (MA Certification).
FAQ
Q: What types of projects is this machine suitable for?
A: It is primarily used for projects requiring shotcrete, such as tunnels, mines, water conservancy projects, subways, and roads. It is particularly well-suited for construction sites with limited space and high efficiency requirements.
Q: What scale of construction can its pumping capacity support?
A: With a maximum pumping pressure of 35 MPa, it can reach a pipeline length of 20 meters and a vertical height of 12 meters, fully meeting the continuous construction needs of small and medium-sized projects.
Q: How many workers can one machine replace?
A: On average, it can replace a construction team of 5–8 people, increasing efficiency by 3–5 times and achieving a payback period of approximately 6–12 months.
Q: Is the powertrain optional?
A: Yes, the standard diesel engine is suitable for outdoor construction; electric motor drive can also be customized upon request, making it suitable for urban construction sites.
Q: Is the machine easy to transport and move?
A: It is equipped with a self-propelled chassis for flexible operation and can be trailered for transport. It is road-legal and easy to load and unload.
Q: What is the after-sales service guarantee?
A: We provide operation manuals, maintenance videos and remote technical guidance, and supply a full range of spare parts to ensure that subsequent sales to wholesale customers are guaranteed.
